Screw the adjusting screw (6) into the body (3).

7

Slide the juice channel (5) over the adjusting screw until

it snaps on the body (3) – “click”.

8

Attach the assembled juicer to the drive unit in the same

way as the mincer body.

9

Insert the adaptor

I

into the bowl

II

. Insert the bowl

(7b) and the pusher (8) – from the mincer unit – onto the

feeding tube.

10

Place the appropriate dishes for the juice and pomace

under the outlet of the juice channel (5) and the adjusting

screw (6).

11

Plug in the appliance.

12

Turn the appliance on by means of the switch button

(1a), and then feed the fruit, pushing with the pusher.

In order for the juice squeezing process to run

properly do not screw the adjustment screw

too deeply in the initial operation phase. After

assessing the amount of juice in the processed

fruits, adjust the screw in order to obtain an

adequate effectiveness and to avoid clogging

the appliance.

●

Observe the pomace dryness during squeezing. If it

is too dry, unscrew the adjusting screw (6), to avoid

clogging the appliance with the pomace.

The screw adjustment depends on the type of

processed fruits, in case of juicy and ripe fruits

adjust the screw deeper, and for fruits that

are not as juicy, the level of screw adjustment

should be lower.

If the screw adjustment does not provide an

adequate squeezing effectiveness, you can

process the pomace once again.

The clogging of the chamber outlet (in the

adjustment screw (3)) with the pomace of juicy

fruits can cause the ooding of the drive unit.

●

Unplug the appliance if the chamber outlet becomes

clogged. Pay special attention on the juice squeezing

process, make sure the screen openings are not clogged.

Disconnect the juicer from the drive unit (as in the case

of the mincer body), dismantle the juicer, clean (wash)

the juicer elements. Use the included brush to clean the

appliance, especially the screen.

After the work has been nished

●

Turn the meat mincer off and pull the power cord out

from the network supply socket.

1a

Remove the pusher (8) and remove the food tray off the

mincing chamber (2) or the shredder chamber.

1b

Remove the pusher (8) and remove the shredder bowl

with an adaptor (7b) off the mincing chamber (2) or the

shredder bowl off the shredder chamber.

K

The device with milling cavity and cookies

forming set assembled can operate without any

break not longer than 10 min.

Juicer

The juicer is an accessory for some types of mincers.

It allows squeezing juice from fruits such as: raspberries,

currants, strawberries, gooseberry and additionally from

grapes and tomatoes. Berry fruits such as currants can

be squeezed with stalks. Fruits with large stones, such as

plums, cherries etc. can be squeezed in the appliance after

removing the stones.

Parts of the juicer:

1

Chamber

2

Worm

3

Body

4

Nut

5

Juice channel

6

Adjusting screw

7b

I

Adaptor

II

Shredder bowl

8

Pusher (from the mincer unit)

9

Screen – 2 pieces

No. 1 – smaller openings

No. 2 – larger openings

10

Large sealing ring for the body (3)

11

Small sealing ring for the worm (2)

12

Hook

13

Brush

Use only the pusher to push fruits (8).

PREPARING THE JUICER FOR OPERATION

AND ITS OPERATION

1

Make sure that the sealing rings (10) and (11) are tted

onto the body (3) and the worm (2). If not, insert them into

the sealing grooves in these elements (the body and the

worm).

2

Insert the screen (9) into the body (3) and press rmly

home.

In order to remove the sieve (9) out of the body

(3), it is helpful to use the hook (12). Put the

shorter end of the hook (12) into the hole of the

sieve (9), and pull the sieve (9) outside.

3

Insert the worm (2) into the chamber (1).

4

Insert the body with the screen onto the worm making

sure that the sieve faces downwards , and the positioning

slot ts into the protrusion in the chamber.

5

Screw on the nut (4) to attach the body to the chamber (1).

L

M
