6

will be unworkable.

34. Children should be supervised to

ensure that they do not play with the

appliance.

35. The lamp inside the product is used

for lighting of the product. This lamp

is not suitable for household room

illumination.

37. Device Group 2 Class B

This device is a Group 2 because it

intentionally produced the radio

frequency energy to treat the material

and is intended to be used in a local

home or a facility connected directly to

the distribution of electricity at low

voltage supplying domestic premises

(Class B).

Household use only

Product description

1) Door lock

Microwave oven door must be properly

closed in order for it to operate.

2) Viewing window

Allow user to see the cooking status.

3) Rotating axis

The glass turntable sits on the axis, the

motor underneath it drives the turntable

to rotate.

4) Rotating ring

The glass turntable sits on its wheels, it

supports the turntable and helps it to

balance when rotating.

5) Turntable

The food sits on the turntable, its

rotation during operation helps to cook

food evenly.

- Place the rotating ring first, and then

- Fit the turntable onto the rotating axis

and make sure that it is geared in

properly.

6) Control panel

See below in details (the control panel

is subject to change without prior

notice).

7) Waveguide cover

I t i s i n s i d e t h e m i c r o w a v e o v e n , n e x t t o

the wall of control panel, please see

figure below.

8) Never remove the waveguide cover.

7

OPERATION OF CONTROL PANEL

1) Timer

- The max cooking time length that

can be set is 30 minutes.

- Each setting is 2 minutes.

- A bell ring will be heard when the

timer times out and returns to Zero

position.

2) Fu nction / Po wer knob

There are 6 power levels:

The following table provides a reference

defrost time length for various food:

WEIGHT

RANGE

DEFROST

LENGTH

Meat 0.1~1.0kg 1:30~26:00

P o u l t r y 0 . 2 ~ 1 . 0 k g 2 : 3 0 ~ 2 2 : 0 0

Seafood 0.1~0.9kg 1:30~14:00

OPERATION

1) Connect the cord

- Before connecting the cord, make sure

the timer is set to “0” position.

- Do not block the ventilation.

2) Place the food on the glass turntable

and close the door.

- Food must be contained in a utensil.

3) Select the desired power level.

4) Set the timer.

I f d e s i r e d t i m e i s l e s s t h a n 1 0 m i n u t e s ,

turn the timer knob to over 10 minutes

position and then turn back to the

desired time setting.

5) Once the desired time is set, the

cooking begins. If pausing in

between is needed, just open the

door at any time, and close it to

resume operation.

6) When it times out and cooking ends,

the microwave oven produces a bell

ring, the inside lamp will also be

automatically turned off.

7) If food is removed before time out,

make sure to set back the timer to “0”

position, this avoids the microwave

oven from operating in empty load.

DEFROST TIPS

Microwave penetrates around 4cm into

most food, to maximize defrosting

effect, the followings are advised:

1) F o r t h i c k a n d c h u n k y f o o d , t u r n t h e

food regularly during operation in

order to obtain uniform heating

effect

2) I f f o o d i s o v e r 0 . 5 K g , i t i s a d v i s e d t o

turn at least 2 times.

3) Defrosted food should be consu med

as soon as possible, it is not advised

to put back to fridge and freeze

again.

COOKING TIPS

The following factors may affect the

cooking result:

H

igh

100%

power

output

(Quick

cooking)

M.High 85% power

output

(Normal

cooking)

Med 66% power

output

(Slow

cooking)

M.Low 40% power

output

(Drinks or

soup)

Defrost 37% power

output

(Defrost)

Low 17% power

output

(Keep

warm)
