IMPORTANT SAFEGUARDS

u Household use only. Do not use for

industrial purpose.

u Unplug from outlet when

assembling and disassembling the unit.

u Close supervision is necessary when

any appliance is used near children.

u When carrying the unit be sure to

hold the motor housing with both hands.

Do not carry the unit by holding only

the hopper plate or head.

u Do not fix the cutting blade and

cutting plate when using kebbe

attachment.

u Never feed food by hand. Always

use food pusher.

u Do not grind hard food such as

bones, nuts, etc.

u Do not grind ginger and other

materials with hard fiber.

u Continuous running of meat grinder

should be not more than 10 minutes

with the following 10 minutes interval

for motor cooling.

u Reverse function is prohibited while

the appliance is operating (For example

switch “ON” knob to “R” knob or on the

contrary), wait at least one minute until

grinder has come to a complete stop，

otherwise it may cause an abnormal

noise, vibration or a transitory electric

spark in the appliance. It could result

easily damage to appliance and make a

user frightened.

u After use, there would be a little

food left in the grinder head. This is

normal. There might be a bit of black

metal powder adhering to the food

ground in the end. Please pick them out

and throw away, do not eat them.

u To avoid jamming, do not force to

operate the unit with excessive

pressure.

u When the circuit breaker activates,

do not switch on.

u Never try to replace the parts and

repair the unit by yourself.

FOR THE FIRST TIME

u Check that voltage indicated on

the rating label corresponds to the

mains voltage in your home.

u Wash all parts (except body) in

warm soapy water.

u Before plugging in, ensure the

“ON/0/ R” switch is turned to "O"

position.

INSTRUCTION FOR USE

ASSEMBLING

u Holding the head, insert it in the

5

inlet (fig.1). Rotate the head in the

same direction as fig.2 until a small

sound can be heard. The head has been

placed in the inlet. Try to rock the head

slightly to ensure it is placed well.

u Place the feed screw into the head,

long end first, by turning the feed screw

slightly until it is set into the motor

housing (fig.3).

u Place the cutting blade onto the

feed screw shaft with the blade facing

the front as illustrated (fig.4). If it is not

fitted properly, meat will not be ground.

u Place the desired cutting plate next

to the cutting blade, fitting protrusions

in the slots (fig.5).

u Support or press the centre of the

cutting plate with one finger then screw

the fixing ring until tight with another

hand (fig.6). Do not over tighten.

u Place the hopper plate on the head

and fix into position.

u Locate the unit on a firm place.

u The air passage at the bottom and

the side of the motor housing should be

kept free and not blocked.

MINCING MEAT

u Cut all foods into pieces (Sinewless,

boneless and fatless meat is

recommended, approximate size: 20

mm x 20 mm x 60 mm) so that they fit

easily into the hopper opening.

u Plug in and turn the “ON / R” switch

to "ON" position, then turn the “ON/0/

R” switch to "ON" position.

u Feed foods into the hopper plate.

Use only the food pusher (fig.7).

u After use switch the unit off and

unplug it from the power supply.
