Black plate (4,1)

Removing the front panel

1 Press the detach button to release the front

panel.

2 Push the front panel upward (M) and then pull

it toward (N) you.

3 Always store the detached front panel in a pro-

tective case or bag.

Re-attaching the front panel

1 Slide the front panel to the left.

2 Press the right side of the front panel until it is

firmly seated.

Forcing the front panel into place may result in

damage to the front panel or head unit.

Turning the unit on

1 Press SRC/OFF to turn the unit on.

Turning the unit off

1 Press and hold SRC/OFF until the unit turns

off.

Selecting a source

1 Press SRC/OFF to cycle between:

RADIO—CD—USB—AUX

! USB MTP displays while the MTP connection

is in use.

Adjusting the volume

1 Turn M.C. to adjust the volume.

Note

When this unit’s blue/white lead is connected to

the vehicle’s auto-antenna relay control termi-

nal, the vehicle’s antenna extends when this

unit’s source is turned on. To retract the anten-

na, turn the source off.

Frequently used menu

operations

Returning to the previous display

Returning to the previous list (the folder one level

higher)

1 Press

/DIMMER.

Returning to the ordinary display

Canceling the main menu

1 Press BAND.

Returning to the ordinary display from the list

1 Press BAND.

Radio

Basic operations

Selecting a band

1 Press BAND until the desired band (FM1,

FM2, FM3 for FM or MW/LW) is displayed.

Switching preset stations

1 Press c or d.

! Select PCH (preset channel) under SEEK to

use this function.

Manual tuning (step by step)

1 Press c or d.

! Select MAN (manual tuning) under SEEK to

use this function.

Seeking

1 Press and hold c or d, and then release.

You can cancel seek tuning by briefly pressing

c or d.

While pressing and holding c or d, you can

skip stations. Seek tuning starts as soon as

you release c or d.

Notes

! For details about SEEK, refer to SEEK (left/

right key setting) on page 5.

! This unit’s AF (alternative frequencies

search) function can be turned on and off.

AF should be off for normal tuning operation

(refer to AF (alternative frequencies search)

on page 5).

Storing and recalling stations

for each band

Using preset tuning buttons

1 To store: Press and hold down one of the

preset tuning buttons (1/

to 6/ ) until

the number stops flashing.

2 To recall: Press one of the preset tuning

buttons (1/

to 6/ ).

Switching the display

Selecting the desired text information

1 Press DISP to cycle between the following:

! FREQUENCY (program service name or

frequency)

! BRDCST INFO (program service name/PTY

information)

! CLOCK (source name and clock)

Notes

! If the program service name cannot be ac-

quired in FREQUENCY, the broadcast fre-

quency is displayed instead. If the program

service name is detected, the program serv-

ice name will be displayed.

! Depending on the band, text information can

be changed.

! Text information items that can be changed

depend on the area.

Using PTY functions

You can tune in to a station using PTY (program

type) information.

Searching for an RDS station by PTY information

1 Press

(list).

2 Turn M.C. to select a program type.

NEWS/INFO—POPULAR—CLASSICS—

OTHERS

3 Press M.C. to begin the search.

The unit searches for a station broadcasting

that type of program. When a station is found,

its program service name is displayed.

! To cancel the search, press M.C. again.

! The program of some stations may differ

from that indicated by the transmitted PTY.

! If no station is broadcasting the type of

program you searched for, NOT FOUND is

displayed for about two seconds and then

the tuner returns to the original station.

PTY list

For more details about PTY list, visit the follow-

ing site:

http://www.pioneer.eu/eur/products/25/121/tech/

CarAudio/PTY.html

Function settings

1 Press M.C. to display the main menu.

Using this unit

4

Section

Using this unit

En

02

<QRD3204-A>4
