Register your product and get support at

HR7782

www.philips.com/welcome

Specifications are subject to change without notice

© 2015 Koninklijke Philips N.V.

All rights reserved.

3140 035 32143

English

1 Important

Read this user manual carefully before you use the appliance, and save the user manual for

future reference.

Danger

• Do not immerse the motor unit in water nor rinse it

under the tap.

Warning

• Never use your ngers or an object to push

ingredients into the feeding tube while the appliance

is running. Only use the pusher.

• Before you connect the appliance to the power,

make sure that the voltage indicated on the bottom

of the appliance corresponds to the local power

voltage.

• Never connect this appliance to a timer switch, to

avoid a hazardous situation.

• Do not use the appliance if the power cord, the

plug, protecting cover, rotating sieve or any other

parts are damaged or has visible cracks.

• If the power cord is damaged, you must have it

replaced by Philips, a service center authorized

by Philips, or similarly qualied persons to avoid a

hazard.

• This appliance shall not be used by children. Keep

the appliance and its cord out of reach of children.

• This appliance can be used by persons with reduced

physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given

supervision or instruction concerning use of the

appliance in a safe way and if they understand the

hazards involved.

• For their safety, do not allow children to play with

the appliance.

• Never let the appliance run unattended.

• If food sticks to the wall of the blender jar or bowl,

switch off the appliance and unplug it. Then use a

spatula to remove the food from the wall.

• Be careful when you are emptying the bowl, handle

or clean the discs, the blade units and the juicer

sieve. The cutting edges are very sharp.

• Do not touch the blades, especially when the

appliance is plugged in. The blades are very sharp.

• If the blades get stuck, unplug the appliance before

you remove the ingredients that block the blades.

• Be careful if hot liquid is poured into the food

processor or blender as it can be ejected out of the

appliance due to a sudden steaming.

• This appliance is intended for household use only.

Caution

• Never switch off the appliance by turning the

blender jar, the bowl, or their lids. Always switch off

the appliance by turning the speed selector to 0 or

OFF.

• Unplug the appliance immediately after use.

• Always wait until the moving parts stop running,

then switch off and unplug the appliance before

opening the lid and reaching into any of the parts

that move in use.

• Always switch off and unplug the appliance if it is left

unattended, and before assembling, disassembling,

cleaning and changing accessories, or approaching

parts that move in use.

• Thoroughly clean the parts that come into contact

with food before you use the appliance for the rst

time. Refer to the instructions and table for cleaning

given in this manual.

• Never use any accessories or parts from other

manufacturers that Philips does not specically

recommend. If you use such accessories or parts,

your guarantee becomes invalid.

• Do not exceed the maximum level indication on

the bowl or the jar. Follow the quantities, processing

time and speed as indicated in the user manual.

• Let hot ingredients cool down (< 80ºC) before

processing them.

• Always let the appliance cool down to room

temperature after each batch that you process.

• Certain ingredients such as carrots may cause

discolorations on the surface of the parts. This

does not have a negative effect on the parts. The

discolorations usually disappear after some time.

• Noise level: Lc = 85 dB [A]

Electromagnetic elds (EMF)

This Philips appliance complies with all standards regarding electromagnetic elds (EMF). If

handled properly and according to the instructions in this user manual, the appliance is safe

to use based on scientic evidence available today.

Recycling

Your product is designed and manufactured with high quality materials and

components, which can be recycled and reused.

When you see the crossed-out wheel bin symbol attached to a product, it means the

product is covered by the European Directive 2002/96/EC:

Never dispose of your product with other household waste. Please inform yourself

about the local rules on the separate collection of electrical and electronic products.

The correct disposal of your old product helps prevent potentially negative

consequences on the environment and human health.

2 Introduction

Congratulations on your purchase and welcome to Philips! To fully benet from the support

that Philips offers, register your product at www.philips.com/welcome.

For recipes to use with your food processor, go to www.philips.com/kitchen

3 Food processor

Warning

• Never use your ngers or an object (for example, a spatula) to push ingredients into the

feeding tube while the appliance is running. Only use the pusher.

Chopper knife

Before you start, make sure you assemble according to Fig. 2.

You can use the chopper knife to chop, mix, blend, or puree ingredients. You can also use it

to mix and blend cake batters.

Caution

• Do not use the chopper knife to chop hard ingredients, like coffee beans, turmeric, nutmeg,

and ice cubes, as this may cause the blade to get blunt.

Note

• Do not let the appliance run too long when you chop (hard) cheese or chocolate. Otherwise

these ingredients become too hot, start to melt, and turn lumpy.

• Precut large pieces of food into pieces of approx. 3 x 3 x 3 cm.

1 Turn the the bowl clockwise to x it on the motor unit, and then put the tool holder

in the bowl.

» When the bowl is xed correctly, you hear a click.

2 Put the chopper knife on the tool holder.

3 Put the ingredients in the bowl.

4 Put the lid on the bowl, and then turn the lid clockwise to x it.

» When the lid is assembled correctly, you hear a click and the lid is xed to the

bowl handle.

5 Put the pusher into the feeding tube.

6 Connect the power plug to the power supply.

7 Check the preparation time, the maximum amount and the speed setting required for

the ingredients in Table 1. Turn the knob to the desired speed setting.

8 After use, turn the knob to 0, and then unplug the appliance.

Tip

• When you chop onions, turn the knob to P a few times to prevent the onions from

becoming too nely chopped.

• When the food sticks to the blade or inside the bowl, you can do the following steps: 1.

Switch off the appliance, and then unplug it. 2. Remove the lid from the bowl. 3. Remove the

ingredients from the blade or from the side of the bowl with a spatula.

Serrated blade

Before you start, make sure you assemble according to Fig. 3.

Use the serrated blade to crush frozen fruit.

Note

• Always put the blade unit in the bowl before you start.

• It is recommended to cut the fruit into 2x2x2cm cube size before having it frozen.

• For making fruit desserts, it is recommended to use speed 2 for smooth result, and speed 1

for chunky result.

1 Turn the the bowl clockwise to x it on the motor unit, and then put the tool holder

in the bowl.

» When the bowl is xed correctly, you hear a click.

2 Put the serrated ice blade on the tool holder.

3 Put the frozen fruit in the bowl.

4 Put the lid on the bowl, and then turn the lid clockwise to x it.

» When the lid is assembled correctly, you hear a click and the lid is xed to the

bowl handle.

5 Put the pusher into the feeding tube.

6 Connect the power plug to the power supply.

7 Turn the knob to 1 or 2 .

8 After use, turn the speed selector to 0, and then unplug the appliance.

Kneading accessory

Before you start, make sure you assemble according to Fig. 4.

You can use the kneading tool to knead yeast dough for bread and pizzas. You need to

adjust the amount of liquid to form the dough according to the humidity and temperature

condition.

Note

• Do not use the kneading tool to blend cake batters. Use the chopper knife for this job.

• Always put the kneading tool in the bowl before you add the ingredients.

Tip

• If using High Gluten Flour, for best results, use 60g water for every 100g of our, and knead

at speed 1 for 2 minutes (max time).

1 Turn the the bowl clockwise to x it on the motor unit, and then put the tool holder

in the bowl.

» When the bowl is xed correctly, you hear a click.

2 Put the kneading tool on the tool holder.

3 Put the ingredients in the bowl.

4 Put the lid on the bowl, and then turn the lid clockwise to x it.

» When the lid is assembled correctly, you hear a click and the lid is xed to the

bowl handle.

5 Put the pusher into the feeding tube.

6 Connect the power plug to the power supply.

7 Turn the knob to the 1 position.

8 Check the preparation time, the maximum amount and the speed setting required for

the ingredients in Table 1.

9 After use, turn the knob to 0, and then unplug the appliance.

Balloon beater

Before you start, make sure you assemble according to Fig. 5:

1 Put the tool holder in the bowl.

2 Put the balloon beater on the tool holder in the bowl.

3 Put the ingredients in the bowl.

4 Put the lid on the bowl. Turn the lid clockwise to x it. Put the pusher in the feeding

tube.

5 Select speed 1.

6 After use, turn the speed selector to 0, and then unplug the appliance.

Tip

• If you want to make better cake, please use balloon beater.

Citrus press

Before you start, make sure you assemble according to Fig. 6.

You can use the citrus press to squeeze citrus fruits.

1 Turn the the bowl clockwise to x it on the motor unit, and then put the tool holder

in the bowl.

» When the bowl is xed correctly, you can hear a click .

2 Put the sieve for citrus press on the tool holder in the bowl. Make sure that the

projection on the sieve is locked in the slot of the bowl handle.

» When the sieve is xed correctly, you can hear a click .

3 Put the cone on the sieve.

4 Connect the power plug to the power supply.

5 Check the maximum amount required for the ingredients in Table 1. Turn the knob to

speed 1.

» The cone starts rotating.

6 Press the citrus fruit onto the cone.

7 Stop pressing from time to time to remove the pulp from the sieve. When you nish

pressing or when you want to remove the pulp, turn the knob to 0 and remove the

bowl from the appliance with the sieve and cone on it.

EN User manual

BG Ръководство за потребителя

CS Příručka pro uživatele

ET Kasutusjuhend

HR Korisnički priručnik

HU Felhasználói kézikönyv

KK Қолданушының нұсқасы

LT Vartotojo vadovas

LV Lietotāja rokasgrāmata

PL Instrukcja obsługi

RO Manual de utilizare

RU Руководство пользователя

SK Príručka užívateľa

SL Uporabniški priročnik

SR Korisnički priručnik

UK Посібник користувача

Slicing discs and shredding discs

Before you start, make sure you pick your desired disc and assemble according to Fig. 7:

• Adjustable slicing disc to adjust different thickness

• Reversible shredding disc (bigger or small size)

Caution

• Be careful when you handle the disc. It has a very sharp cutting edge.

• Never use the disc to process hard ingredients, like ice cubes.

• Do not exert too much pressure on the pusher when you press ingredients into the feed

tube.

4 Cleaning

Warning

• Before you clean the appliance, unplug it.

Caution

• Make sure that the cutting edges of the blades and discs do not come into contact with hard

objects. This may cause the blade to get blunt.

• The cutting edges are sharp. Be careful when you clean the blade unit of the food processor

and the discs.

1 Clean the motor unit with a moist cloth.

2 Clean the other parts in hot water (< 60ºC) with some washing-up liquid or in a

dishwasher.

Quick cleaning

You can follow the following steps to clean the food processor bowl and blender jar easier.

Note

• Make sure that the blade is assembled in the bowl if you clean the food processor bowl.

1 Pour lukewarm water (not more than 0.5 liters) and a few drops of washing-up liquid

into the food processor bowl.

2 Place the lid on the food processor bowl, and then turn it clockwise to x it.

3 Turn the knob to P. Let the appliance run for 30 seconds or until the food processor

bowl is clean.

4 After use, turn the knob to 0, and then unplug the appliance.

5 Detach the food processor bowl and rinse it with clean water.

5 Storage

1 Push the power cord into the integrated cord storage (Fig. 10).

2 Store the product in a dry place.

3 Put the discs, kneading tool and shaft, and other small accessories in the food processor

bowl (Fig. 11).

6 Guarantee and service

If you have a problem, need service, or need information, see www.philips.com/support or

contact the Philips Consumer Care Center in your country. The phone number is in the

worldwide guarantee leaet. If there is no Consumer Care Center in your country, go to

your local Philips dealer.

1

2 min 1 kg 1

20 sec 500 g1

30 sec 1 kg

1

30 sec 200 g

1

30 sec 3 pcs

1

30 sec 1 kg

1

(MAX)

(MAX)

(MAX)

(MAX)

5 x 1 sec 750 gP

5 x 1 sec 1 kg P/2

30 sec 100 gP

60 sec 1 kg 2

45 sec 500 g2

30 sec 400 g2

750 ml

8 pcs

1

1

30 sec 1 kg1

30 sec 1 kg1

2

min 1 kg

600 ml

1

60-180 sec

60-300 sec

P

0

1

2

30 sec 750 g 1

30 sec 3 pcs 1

30 sec 3 pcs 1

750 g 1-260-180 sec

-4

o

C

10

11

12

0

1

P

2

9

6

5

2 3 4

-4

o

C

8

7

Рейтинг

Подробнее об этом руководстве

Мы понимаем, что приятно иметь бумажное руководство для вашего Philips HR7782 Кухонный комбайн. Вы всегда можете скачать инструкцию с нашего сайта и распечатать самостоятельно. Если вы хотите получить оригинальное руководство, мы рекомендуем вам связаться с Philips. Возможно, они смогут предоставить оригинальное руководство. Вы ищете руководство для вашего Philips HR7782 Кухонный комбайн на другом языке? Выберите предпочитаемый язык на нашей домашней странице и найдите номер модели, чтобы узнать, есть ли она у нас в наличии.

Технические характеристики

Все инструкции для Philips Кухонные комбайны
Больше руководств Кухонные комбайны

Часто задаваемые вопросы о Philips HR7782 Кухонный комбайн

Наша служба поддержки выполняет поиск полезной информации по изделиям и отвечает на часто задаваемые вопросы. Если вы заметили неточность в наших часто задаваемых вопросах, сообщите нам об этом с помощью нашей контактной формы.

Сопутствующие товары

Руководство

Philips HR7778 Avance Collection Кухонный комбайн

Руководство

Philips HR7772 Кухонный комбайн

Руководство

Philips HR7638 Cucina Кухонный комбайн

Руководство

Philips HR7756 Essence Кухонный комбайн

Руководство

Philips HR7764 Essence Кухонный комбайн

Руководство

Philips HR7770 Кухонный комбайн

Руководство

Philips HR7974 Avance Collection Кухонный комбайн

Руководство

Philips HR7766 Кухонный комбайн

Связанные категории
