For connection values, see type plate/technical data.

ATTENTION

Impurities in the water can damage the high-pressure

pump and the accessories. For protection, the use of

the KÄRCHER water filter (optional accessory, order

no. 4.730-059) is recommended.

Observe regulations of water supplier.

ATTENTION

Hose couplings made of metal with aquastop can dam-

age the pump! Please use plastic couplings or KÄRCH-

ER brass couplings.

Illustration

 Screw the coupling element to the water connec-

tion on the appliance.

 Attach the water supply hose to the coupling on the

water connection.

 Connect the water supply hose to the water supply.

 Completely open the water tap.

This high-pressure cleaner is suited to work with the

KÄRCHER suction hose with backflow valve (Optional

accessory, order no. 2.643-100) to draw in surface wa-

ter, e.g. from water butts or ponds (see specifications for

max. suction height).

Note: With vacuuming operation, the coupling for the

water connection is not required.

 Fill the suction hose with water.

 Screw the suction hose into the water connection of

the appliance and insert it into the water source

(e.g. rainwater drum).

Bleed the device as follows prior to operation:

 Turn on the appliance “I/ON”.

 Unlock the lever of the trigger gun.

 Push the lever of the trigger gun, the device will

switch on.

 Using the +/- buttons, set the high-pressure gun to

detergent level 1.

 Let the device run (max. 2 minutes) until the water

exits the trigger gun without bubbles.

 Release the lever of the trigger gun.

 Lock the lever of the trigger gun.

ATTENTION

Dry running of more than 2 minutes leads to damage of

the high-pressure pump. If the appliance does not build

up pressure within 2 minutes, switch the appliance off

and proceed in accordance with the instructions in

Chapter "Troubleshooting".

The +/- buttons on the high-pressure gun can be used

to select the pressure and detergent dosing levels. It is

possible to change spray type by turning the 3-in-1 multi

jet spray lance.

ATTENTION

The sensitivity of the materials can strongly differ de-

pending on the age and the condition. The so-called

recommendations are non-binding.

Note: The pressure indicator is not significant during

operation with the T-Racer and other accessories.

몇 CAUTION

Keep a distance of at least 30 cm when using the jet for

cleaning painted surfaces to avoid damage.

ATTENTION

Car tyres, paint or sensitive surfaces such as wood

should not be cleaned with the dirt blaster, as there is a

risk of damage.

Illustration

 Push the 3-in-1 multi jet spray lance into the high-

pressure gun and fasten it by a 90° rotation (ob-

serve alignment!).

 Select spray type, by turning the 3-in-1 multi jet

spray lance until the required spray display is visi-

ble above.

 Turn on the appliance “I/ON”.

 Unlock the lever of the trigger gun.

 Push the lever of the trigger gun, the device will

switch on.

Note: Release the lever of the trigger gun; the de-

vice will switch off again. High pressure remains in

the system.

Water supply

Water supply from mains

Drawing in water from open reservoirs

Operation

Full Control Plus System

Pressure level For example, recommend-

ed for

Flat jet nozzle

Stone terraces, asphalt, met-

al surfaces, garden utensils

(wheelbarrow, spade, etc.)

Motorcar / motorcycle, brick

surfaces, plastered walls,

plastic furniture

Wooden surfaces, bicycles,

sand stone surfaces, rattan

furniture

Dirt grinder

For especially stubborn dirt

on stone terraces, asphalt,

metal surfaces, garden uten-

sils (wheelbarrow, spade,

etc.)

Detergent nozzle

Operation with detergent.

Dosing the detergent concen-

tration as needed.

High pressure operation

13EN
