Руководство Indesit DI9E 2B10 Посудомоечная машина

Руководство

4

OPTIONS AND FUNCTIONS

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL).

If an option is not compatible with the selected program see PROGRAMS TABLE, the corresponding LED ashes rapidly 3 times

and beeps will sound. The option will not be enabled.

MULTIZONE

If there are not many dishes to be washed, a half loading may

be used in order to save water, electricity and detergent.

Select the program and then press the MULTIZONE button:

the indicator over the button lights up and the symbol of the

chosen rack will appear on the display.

By default the appliance washes dishes in all racks.

To wash only the specic rack, press this button repeatedly:

shown on the display (only lower rack)

shown on the display (only upper rack)

shown on the display (only cutlery rack)

shown on the display (option is OFF and the appliance will

wash dishes in all racks).

Remember to load the upper or lower rack only, and to

reduce the amount of detergent accordingly.

If upper rack is removed, please apply detergent directly

to tub instead of detergent dispenser.

TABLET (Tab)

This setting allows you to optimize the performance of the

program according to the type of detergent used.

Press the SANI RINSE button for 3 seconds (the correspon-

ding symbol will light up) if you use combined detergents in

tablet form (rinse aid, salt and detergent in 1 dose).

If you use powder or liquid detergent, this option should

be o.

SANI RINSE

This option can be used to sanitize washed dishes.

It will increase nal rinse temperature and add antibacterial

wash to the selected program.

Select the washing program, press the SANI RINSE button; the

indicator light will light up. To deselect the option, press the

same button again. Ideal to clean crockery and feeding bottles.

The dishwasher door must be kept shut for the entire duration

of the program in order to guarantee reduction of germs. If the

door is opened the indicator lamp starts ashing.

WARNING: the crockery and plates could be extremely hot

at the end of the cycle.

DELAY

The start of the program may be delayed for a period of time

between 0:30 and 24 hours.

1. Select the program and any desired options. Press the

DELAY button (repeatedly) to delay the start of the program.

Adjustable from 0:30 to 24 hours. With each press of the

button, the delay start increases by: 0:30 if selection below

4 hours, 1:00 if selection is below 12 hours, 4 hours if

selection is above 12 hours. If 24 hours reached, and the

button is pressed, the delayed start is deactivated.

2. Press the START/PAUSE button: the timer will begin counting

down;

3. Once this time has elapsed, the indicator light switches o

and the program begins automatically.

If at the time of the countdown the START/PAUSE button is

pressed again the DELAY option is cancelled and the selected

program starts automatically.

The DELAY function cannot be set once a program has

been started.

KEYLOCK

A long press (for 3 seconds) of MULTIZONE button, will activate

the KEYLOCK function. The KEYLOCK function will block the

control panel except the ON/OFF button. To deactivate the

KEYLOCK, long press again.

WATER TAP CLOSED – Alarm

Flashes when there is no inlet water or water tap is closed.

DRAIN OUT

To stop and cancel the active cycle, the DRAIN OUT function

can be used.

A long press of START/PAUSE button, will activate the DRAIN

OUT function. The active program will be stopped and the water

in the dishwasher will be drained out.

NaturalDry

NaturalDry is a convection drying system which automatically opens

the door during/after drying phase to ensure exceptional drying per-

formance every day. Door opens at the temperature that is safe to your

kitchen furniture, thus door will not be opened when the option of

SANI RINSE is on.

As additional steam protection, special designed protection foil is added

together with the dishwasher (depending on the model type - can be

the need to buy it). To see how to mount protection foil please refer to

(INSTALLATION GUIDE).

NaturalDry functionality could be disabled by the user as follows:

• To DISABLE: Switch On, then switch O the machine. Keep the P

button pressed for 5 sec., at the end of 5 sec the dishwasher plays a

short beep. Switch On the machine, the display shows „oOF”.

• To ENABLE: Switch On, then switch O the machine. Keep the P but-

ton pressed for 5 sec., at the end of 5 sec the dishwasher plays a

short beep. Switch On the machine, the display shows „oOn”.
