8

GB

Start-up and use

WARNING! The oven is

provided with a stop system

to extract the racks and

prevent them from coming

out of the oven (1).

As shown in the drawing,

to extract them completely,

simply lift the racks, holding

them on the front part, and

pull (2).

! The rst time you use your appliance, heat the empty

oven with its door closed at its maximum temperature for

at least half an hour. Ensure that the room is well ventilated

before switching the oven off and opening the oven door.

The appliance may emit a slightly unpleasant odour caused

by protective substances used during the manufacturing

process burning away.

Starting the oven

1. Select the desired cooking mode by turning the

SELECTOR knob.

2. Select the desired temperature with the THERMOSTAT

knob. See the Cooking advice table for cooking modes and

the suggested cooking temperatures (see Cooking Modes).

3. When lit, the THERMOSTAT indicator light indicates that

the oven is heating up to the temperature set.

4. You may do the following during cooking:

- change the cooking mode by turning the SELECTOR knob.

- change the temperature by turning the THERMOSTAT

knob.

- stop cooking by turning the SELECTOR knob to the “0”

position.

! Never put objects directly on the bottom of the oven; this

will avoid the enamel coating being damaged.

! Always place cookware on the rack(s) provided.

Cooling ventilation

In order to cool down the external temperature of the oven,

some models are tted with a cooling fan that blows out air

between the control panel and the oven door.

! Once cooking has been completed, the cooling fan continues

to operate until the oven has cooled down sufciently.

Oven light

It goes on when selecting with the SELECTOR knob. It

stays on when a cooking mode is selected.

How to use the timer*

1. To set the buzzer, turn the TIMER knob clockwise almost

one complete revolution.

2. Turn the knob anticlockwise to set the desired time: align

the minutes shown on the knob with the indicator on the

control panel.

3. The timer operates in minutes: when the selected time

has elapsed, a buzzer will sound.

! The timer does not turn the oven on or off.

The electronic programmer

DISPLAY

SET TIME

button

END OF

COOKING icon

CLOCK icon

DURATION

icon

TIMER icon

DECREASE TIME

button

INCREASE TIME

button

•• ••

Setting the clock

! The clock may be set when the oven is switched off or

when it is switched on, provided that a the end time of a

cooking cycle has not been programmed previously.

After the appliance has been connected to the mains, or

after a blackout, the icon and the four numerical digits

on the DISPLAY will begin to ash.

1. Press the button several times until the icon and

the four digits on the display begin to ash.

2. Use the “ ” and “ ” buttons to adjust the time; if you

press and hold either button, the display will scroll through

the values more quickly, making it quicker and easier to set

the desired value.

3. Wait for 10 seconds or press the button again to

nalise the setting.

Setting the timer

! This function does not interrupt cooking and does not affect

the oven; it is simply used to activate the buzzer when the

set amount of time has elapsed.

1. Press the button several times until the icon and

the three digits on the display begin to ash.

2. Use the “ ” and “ ” buttons to set the desired time; if you press

and hold either button, the display will scroll through the values

more quickly, making it quicker and easier to set the value.

3. Wait for 10 seconds or press the button again to

nalise the setting.

The display will then show the time as it counts down. When

this period of time has elapsed the buzzer will be activated.

Programming cooking

! A cooking mode must be selected before programming

can take place.

Programming the cooking duration

1. Press the button several times until the icon and

the three digits on the DISPLAY begin to ash.

2. Use the “ ” and “ ” buttons to set the desired duration;

if you press and hold either button, the display will scroll

through the values more quickly, making it quicker and

* Only available in certain models.
