ASSEMBLY INSTRUCTIONS

COMPONENTS CONTROL PANEL

HYF500E

Fig. 1

Fig. 5

Fig. 7 Fig. 8

Fig. 6

Fig. 2 Fig. 3 Fig. 4

ENGLISH GB

IMPORTANT SAFETY INSTRUCTIONS

Read through all the instructions

before starting to use the appliance. Keep

this manual in a safe place for future

reference.

These instructions are also available on

our website. Please visit

www.HelenofTroy.com/emea-en/.

WARNING:

• This appliance must only be operated

as instructed in this user manual.

• This appliance can be used by children

aged from 8 years and above and

persons with reduced physical, sensory

or mental capabilities or lack of

experience and knowledge if they have

been given supervision or instruction

concerning use of the appliance in a

safe way and understand the hazards

involved.

• Children shall not play with the

appliance.

• Cleaning and user maintenance shall

not be made by children without

supervision.

• Clean the appliance regularly by

following the “Cleaning Instructions”.

• This appliance is only designed for

indoor use.

• Unwind the power cord completely.

Failure to do so could cause

overheating and possible fire hazard.

• Do not tug at the power cord to

disconnect the plug. Do not touch the

power cord with wet hands. Do not

remove the power plug from the power

socket while the product is in use.

• Do not use accessories, spare parts

or components not expected and / or

provided by the manufacturer.

• Always switch the appliance off and

disconnect the power plug from the

power socket when the appliance is not

in use or during transport.

• Do not use this appliance if it is

damaged or shows any signs of possible

damage or if it is not functioning

properly. Disconnect the power plug

from the power socket.

• If the supply cord is damaged, it must

be replaced by the manufacturer, its

service agent or similarly qualified

persons in order to avoid a hazard.

• Never touch the unit with wet hands.

COMPONENTS

1. Base

2. Bottom fan

3. Top fan

4. Top fan speed control

5. Bottom fan speed control

6. Oscillation button

FIRST TIME OF USE

1. Read through all the instructions before starting to use the fan.

2. Unpack all the parts of the fan. Remove all packaging materials and

dispose of them for recycling.

3. Place the fan on a firm, even surface. Make sure that it is standing

securely so that it cannot tip or fall over. A safety distance of at least

50 cm from other objects must be observed.

ASSEMBLY INSTRUCTIONS (See page 2)

A. BASE ASSEMBLY

• Align the front and back base pieces and gently push the halves until

the pieces snap securely together. (Fig. 1).

B. SECURING THE TOWER FAN TO THE BASE

• At the base of the housing, remove the locking nut and set aside (Fig. 2)

• Carefully lift the fan housing (Fig. 3) and place the power cord through

the center of the base.

• Lower the fan housing into the base (Fig. 4).

• Take the locking nut and place the power cord through the locking nut

and move the nut up inside the base, (Fig. 5) attach the locking nut to

the fan housing by turning clockwise until fully tightened.

• The fan cord can exit either side of the base; choose which one is closer

to your outlet. (Fig. 6)

• The back of this fan is intentionally closed. This allows the air intake and

exit to happen at the front grille. This aerodynamic cross-flow design

harnesses the Turbo Force® power of your fan!

NOTE: DO NOT operate the tower fan unless it is in its proper, upright

position.

OPERATING INSTRUCTIONS

• Be sure the fans are in the off position.

• Place your fan on a dry, level surface.

• Plug the power cord into a polarized 220 volt AC wall outlet.

Individual controls allow you to operate each fan independently.

TOP FAN SPEED CONTROL

Turn the control knob to the desired fan speed High (

), Medium ( )

or Low ( ) (Fig. 7).

3

4

6

5

2

1

4

6

5

6
