3. Use of the Oven (According to model)

3.1 Display description

WARNING : the first operation to carry out after the oven has been installed or following the interruption

of power supply (this is recognizable the display pulsating and showing ) is setting the correct time. 12:00

The bottom right LED flashes at the same time ( ). This is achieved as follows.

•Set time with buttons."-" "+"

•Push the Menu button or wait 5 seconds than the clock is setted.

ATTENTION: The oven will only operate setting the clock

1. Thermostat selector knob

2. Thermostat signal lamp

3. End of cooking

4. Cooking time

5. Temperature or clock display

6. LCD display adjustment controls

7. Minute minder

8. Clock setting

9. Wifi signal lamp

10. Function selector knob

FUNCTION HOW TO DEACTIVATE WHAT IT DOES

NOTE

HOW TO USE

KEY LOCK

•Child Lock function is activated by

touching Set (+) for a minimum of 5

seconds. From this moment on all

other function are locked and the

display will flash 3 sec intervals STOP

and preset time intermittently.

•Child Lock function is deactivated by

touching touchpad Set (+) again for a

minimum of seconds. From this 5

moment on a l l f u nctions a r e

selectable again.

•Push the central button 3 times

•Press the buttons "-" "+" to set

the required time

•Release all the buttons

•When the set time has elapsed, an

audible alarm is full stop after

activated this alarm will stop on its

own, however it can be stopped

immediately by pressing any button.

•Sounds an alarm at the end of the

set time.

•During the process, the display

shows the remaining time.

•Allows to use the oven as alarm clock

(could be activated either with operating

the oven or with out operating the oven)

•Select the cooking function with the

oven function knob, the temperature

you want to cook with the thermostat

knob.

• Push the central button 1 times

• Press the buttons "-" or "+"to set the

lenght of cooking required

• Release all buttons

NOTE: If the oven is switched off or

the lamp is functioning, the cooking

time schedule function will not work.

• It allows to preset the cooking time

required for the recipe chosen.

• To check how long is left to run press

the MENU button 1 time.

• To alter/change the preset time press

MENU and "-" "+" buttons.

•Push any button to stop the signal.

Push the central button to return to

the clock function.

•At the end of the program the program

gives 3 warning signals and “End” appears

on the display.

Set the function selector switch to "0" to

return to the clock function.

•At the time set, the oven will switch

off. To switch off manually, turn the

oven function selector to position O.

•Enables you to set the end of

cooking time

•To check the preset time push the

central button 2 times

•To modify the preset time press

buttons MENU + "-" "+"

•Select the cooking function with the

oven function knob, the temperature

you want to cook with the thermostat

knob.

•Push the central button times 2

•Press the buttons "-" "+" to set the

time at which you wish the oven to

switch off

•Release the buttons

NOTE: If the oven is switched off or

the lamp is functioning, the cooking

time schedule function will not work.

•This function is typically used with

“cooking time” function.

For example if the dish has to be cooked for

45 minutes and needs to be ready by

12:30, simply select the required

function, set the cooking time to 45

minutes and the end of cooking time to

12:30.

•At the end of the cooking set time, the

oven will switch off automatically and an

audible alarm will ring.

•Cooking will start automatically at 11:45

(12:30 minus 45 mins) and will continue

until the pre-set end-of-cooking-time,

when the oven will switch itself off

automatically.

END OF

COOKING

COOKING

TIME

MINUTE

MINDER

EN 06
