English

! The appliance must be installed by a qualified person in compliance

with the instructions provided.

!

Wear gloves when carrying out installation and maintenance

operations.

If the supply cord is damaged, it must be replaced by the manufacturer,

its service agent or similarly qualified persons in order to avoid a

hazard.

Warning: Failure to install the screws or fixing device in accordance with

these instructions may result in electrical hazards.

IMPORTANT: So as not to damage your product, during installation use

only the screws provided. Make sure these are used as shown in the

following instructions.

Prepare the power supply (see “Warning” sheet).

For the ducting version and version with an external motor, prepare the pipe

for air evacuation (see “Warnings” sheet).

FILTERING OR DUCTING VERSION ?

The hood may be in filtering version, in ducting version or in version with an

external motor. Decide from the outset which type is to be installed.

For better efficiency, we recommend installing the hood in the ducting

version or in version with an external motor (if possible).

Ducting version

The hood purifies the air and evacuates it to the outside through an exhaust

duct.

Version with external motor

The hood purifies the air and evacuates it to the outside through an exhaust

duct. The appliance must be connected to an ducting apparatus/motor which

works on its own using the appliance as a union for the air to be scavenged

Filtering version

The hood purifies the air and recycles the clean air back into the room.

CONTROLS

Only for hoods equipped with electronic control:

(in models sold in Scandinavia, the following features are not present)

The 4th speed (intensive) is automatically lowered to 3rd speed after 5 minutes

of operation to optimise energy consumption; in hoods with voltage 120V/60Hz

this function is not active and the 4th speed is indicated by the letter b

(Booster).

- If the hood is left on (lights and/or motor), after 10 hours in the absence of

commands from the user, it will automatically switch to OFF condition with all

services switched off. In hoods with voltage 120V/60Hz this function is not

active.

- The Buzzer emits a “beep” each time that a command is set from the keyboard

or remote control (optional).

- In the event of interruption of power during the hood, if you restore the hood

in the OFF state, then the engine must be reactivate manually.

Controls of Fig. 1:

A) ON/OFF - lamps. This button is also used for the alarm function of the anti-

grease and charcoal filters.

Filter alarm: After 30h of motor operation, the L1 RED LED comes ON and

remains ON for 30" (the grease filters have to be cleaned). After 120h of motor

operation, the L1 RED LED comes ON and flashes for 30" (the charcoal filters

have to be changed if the hood is so equipped). The Filter Alarm is ONLY given

with the motor is OFF. The Filter Alarm is cancelled (HOUR meter reset) by

holding down button A for 2".

B) Press button B to start the motor at Speed 1. The speed is shown by the

L1 GREEN LED coming ON. When held down for 2", the motor switches off.

A single pressure on the button when the LED is ON activates the timer function

(motor ON for 5'), shown by the flashing LED. To cancel the timer function,

press the button again ONCE.

C) Press button C to start the motor at Speed 2. The speed is shown by the

L2 GREEN LED coming ON.

A single pressure on the button when the led is on activates the timer function

(motor on for 5'), shown by the flashing led. To cancel the timer function, press

the button again ONCE.

D) Press button D to start the motor at Speed 3. The speed is shown by the

L3 GREEN LED coming ON. A single pressure on the button when the led is

on activates the timer function (motor on for 5'), shown by the flashing led.

To cancel the timer function, press the button again ONCE.

E) Press button E to start the il motor at Speed 4. The speed is shown by the

L4 GREEN LED coming ON. A single pressure on the button when the led is

on activates the timer function (motor on for 5'), shown by the flashing led.

To cancel the timer function, press the button again ONCE.

Controls of Fig. 2:

A) ON/OFF - lamps. This button is also used for the alarm function of

the grease and charcoal filters.

Filter alarm: After 30h of motor operation, the L1 LED comes ON and

remains ON (the grease filters have to be cleaned). After 120h of motor

operation, the L1 LED comes ON and flashes (the charcoal filter have

to be changed if the hood is so equipped). The Filter Alarm is ONLY

given with the motor is OFF. The Filter Alarm is cancelled (HOUR meter

reset) by holding down button A for 2".

B) Press button B to start the motor at Speed 1. The speed is shown

by the L2 LED coming ON. When held down for 2", the motor switches

off. A single pressure on the button when the LED is ON activates the

timer function (motor ON for 5'), shown by the flashing LED. To cancel

the timer function, press the button again ONCE.

C) Press button C to start the motor at Speed 2. The speed is shown

by the L3 LED coming ON. A single pressure on the button when the

led is on activates the timer function (motor on for 5'), shown by the

flashing led. To cancel the timer function, press the button again ONCE.

D) Press button D to start the motor at Speed 3. The speed is shown

by the L4 LED coming ON. A single pressure on the button when the

led is on activates the timer function (motor on for 5'), shown by the

flashing led. To cancel the timer function, press the button again ONCE.

E) Press button E to start the il motor at Speed 4. The speed is shown

by the L5 LED coming ON. A single pressure on the button when the

led is on activates the timer function (motor on for 5'), shown by the

flashing led. To cancel the timer function, press the button again ONCE.

Controls of Fig. 3:

A) ON/OFF - lamps. This button is also used for the alarm function of

the grease and charcoal filters.

Filter alarm: After 30h of motor operation, the L1 LED comes ON and

remains ON for 30" (the grease filters have to be cleaned). After 120h

of motor operation, the L1 LED comes ON and flashes for 30" (the

charcoal filter have to be changed if the hood is so equipped). The Filter

Alarm is ONLY given with the motor is OFF. The Filter Alarm is cancelled

(HOUR meter reset) by holding down button A for 2".

B) The button B activates/deactivate sensor function (when activated the

sensor is lit by the LED L2).

C) Press button C to start the motor at Speed 1. The speed is shown

by the L3 LED coming ON. When held down for 2", the motor switches

off.

D) Press button D to start the motor at Speed 2. The speed is shown

by the L4 LED coming ON.

E) Press button E to start the motor at Speed 3. The speed is shown

by the L5 LED coming ON.

F) Press button F to start the il motor at Speed 4. The speed is shown

by the L6 LED coming ON.

SENSOR SENSITIVITY: sensitivity of the sensor may be modified in

accordance with individual requirements. Modify the sensitivity by pressing

simultaneously on the A and B buttons. The set sensitivity level will be

displayed via the 4 flashing Leds - L3, L4, L5, and L6. The desired

sensitivity is set via the C, D, E, and F buttons (C being minimum, F

being maximum). Set the sensitivity level to minimum for gas cook tops,

medium for glass-ceramic cook tops and maximum for induction cook

tops.

WARNING: when led L1lights up, this indicates that the grease or charcoal

filters require cleaning.

FILTER SENSOR (activated via the B button): this device is equipped

with a completely automatic system (Advanced Sensor Control) for

management of all hood functions. Thanks to the Advanced sensor

Control (ASC), air circulating in the kitchen is maintained clean and odour-

free without requiring any user intervention. The sophisticated sensors are

able to capture any type of odour, vapour, smoke or heat caused by

cooking. The ASC also captures any possible irregular gases present in

the environment.

When the sensor function is activated, the C, D, E and F buttons activate

the speed temporarily, to then be overridden by the automatic speed

setting.

Warning: in order to avoid damaging the sensor, never use silicone products

near the hood!

Controls of Fig. 4:

This device is equipped with a completely automatic system (Advanced

Sensor Control) for management of all hood functions. Thanks to the

Advanced sensor Control (ASC), air circulating in the kitchen is maintained
