English

Our products are engineered to meet

the highest standards of quality,

functionality and design. We hope you

thoroughly enjoy your new Braun

appliance.

Please read the use instructions

carefully before first use.

Important

• The blade 9 is very sharp!

Take hold of the blady by the

knob only. After use, always first

remove the blade from the food

processor bowl 6 before removing

the processed food.

• Make sure that your voltage corre-

sponds to the voltage printed on the

bottom of the appliance. Connect

to alternating current only.

• Keep the appliance out of the reach

of children.

• This appliance is not intended for use

by children or persons with reduced

physical or mental capabilities, unless

they are given supervision by a person

responsible for their safety. In general,

we recommend that you keep the

appliance out of reach of children.

• This appliance was constructed for

household use only to process the

listed quantities.

• Do not use any parts in the microwave

oven.

• Do not allow the appliance to operate

unsupervised.

• Braun electric appliances meet

applicable safety standards. Repairs

or the replacement of the mains cord

must only be done by authorised

service personnel. Faulty, unqualified

repair work may cause considerable

hazards to the user.

• Switch the appliance off and discon-

nect it from the outlet before storing it.

Specifications

• Voltage/wattage: See typeplate on the

bottom of the appliance.

• Operating time and max. capacity:

See processing instructions.

Description

The Braun CombiMax meets highest

demands for kneading, mixing, blending,

chopping, slicing, shredding and grating,

both simply and quickly.

1 Motor block

2 Cord storage

3 Motor switch (on = «I», off = «off/0»)

4 Pulse mode «• pulse»

5 Variable speed regulator (2 - 14)

6 Food processor bowl (2 l capacity)

7 Lid for food processor bowl 6

8 Pusher for lid 7

Attachments for food processor

bowl 6

(Important: Not all attachments will be

included in the standard equipment of

all models.)

9 Blade with protective cover

j Insert carrier

q Fine slicing insert – a

l Coarse slicing insert – b

m Fine shredding insert – c

n Coarse shredding insert – d

o Grating insert – e

p French-fries system

q Plastic or metal kneading hook

(depending on model)

r Whipping attachment

Note:

Before using the food processor

for the first time, clean all parts as

described under «Cleaning».

Overload protection

In order to avoid damages caused by

overload, this appliance is equipped with

an automatic security switch which shuts

off the current supply if necessary. In

such case, turn the motor switch 3 back

to «off/0» and wait approx. 15 minutes to

allow the motor to cool off before switch-

ing on the appliance again.

Pulse mode «• pulse» 4

The pulse mode is for example useful

for the following applications:

• Chopping delicate and soft food, e.g.,

eggs, onions or parsley.

• Carefully folding flour into dough or

batter to maintain the creaminess.

• Adding whipped eggs or cream to

more solid food.

The pulse mode «• pulse» is activated

by pressing the blue knob on the

motor switch 4 with switch setting

«off/0».

Before activating the pulse mode, set

the desired speed with the speed regu-

lator 5. When releasing the pulse knob

4, the appliance is switched off.

Recommended speed

ranges for individual attach-

ments

Set the speed range by means of the

variable speed regulator 5. It is recom-

mended to first select the speed and

then switch on the appliance in order to

work whith the desired speed right from

the beginning.

Attachments Speed range

Kneading hook 6

Blade 6 - 14

Whipping attachment:

– egg-whites 5

– cream 3

Slicing, grating and

shredding inserts 2 - 8

French-fries system 2 - 3

(please also refer to product printing)

Double safety feature

The appliance can only be switched on

when the food processor bowl with lid is

properly engaged. If the lid is opened

during operation, the motor switches off

automatically. As in this case the motor

switch 3 is still on «I», turn it back to

«off/0» to avoid switching on the motor

accidentally.

Attaching the food processor

bowl 6 and the lid 7

1. With the motor switched off, place

the food processor bowl onto the drive

place of the motor block 1 matching

the arrow on the bowl with the arrow on

the motor block (A). Then turn the bowl

in the «function» direction as far as it

will go.

2. Put the attachment needed (see

instructions for each of the attachments)

onto the drive shaft of the bowl and

push it down as far as it will go.

3. Put the lid 7 onto the bowl matching

the arrow on the lid with the arrow on

the bowl.

Then turn the lid clockwise guiding its

nose rim into the safety lock opening of

A

1

2

2

• • •

8

CombiMax 650

3

6

6

• • •

14

5

2

• • •

4

off/0

98907295_K600_S06-100 02.04.2009 10:08 Uhr Seite 11
