16 Robert Bosch Hausgeräte GmbH

en

Bowl with accessories/tools

Warning!

When working with the bowl, the appliance

cannot be switched on until the bowl has

been attached and the lid has been attached

and screwed on tight.

Universal blade

for cutting, mincing, mixing.

Kneading hook

for kneading dough and mixing-in

ingredients that ought not be cut

(e.g. raisins and chocolate chips).

Chopping disc

for cream, egg white and

mayonnaise.

Fig.



 Attach the bowl (arrow on bowl on dot

on the appliance) and rotate as far as

possible in a clockwise direction.

 Insert tool holder into the bowl.

 Insert universal blade, whisking disc or

kneading hook into the tool holder and

release.

Note position of the tools when inserting

them! Press tools all the way down.

Warning!

Do not add ingredients until the tools have

been inserted.

 Add ingredients.

 Attach lid with pusher (match arrow on lid

on dot on bowl) and rotate in a clockwise

direction. Lid lug must be located fully in

the slot in the bowl handle.

 Insert the mains plug.

 Set the rotary switch to the desired

setting.

 To add more ingredients, set the rotary

switch to 0

/off.

 Remove the pusher and add ingredients

through the feed tube. Pusher can be

used as a measuring cup.

C

utting discs

Slicing reversible disc – thick/thin

for slicing fruit and vegetables.

Process at setting 1.

Identification on the reversible slicing disc:

“coarse” for the thick cutting side, “fine” for the

thin cutting side

Warning!

The reversible slicing disc is not suitable for

slicing hard cheese, bread, rolls or chocolate.

Slice boiled, waxy potatoes only when they

are cold.

Shredding reversible disc –

c

oarse/fine

for shredding vegetables, fruit

and cheese, except for hard cheese

(e.g. Parmesan).

Process at

setting 1

.

Designation on the reversible shredding disc:

“2” for the coarse shredding side

„4“ for the fine shredding side

Warning!

The reversible shredding disc is not suitable

for shredding nuts. Shred soft cheese with

the coarse side only at setting 2.

Reversible slicing/shredding disc

for slicing and shredding fruit,

vegetables and cheese.

Process at setting 2.

Fig. 

 Attach the bowl (arrow on bowl on dot on

the appliance) and rotate as far as

possible in a clockwise direction.

 Insert tool holder into the bowl.

Depending on the required use:

 Place cutting disc on tool holder. Turn

required slicing/shredding side face up.

Place disc on the disc holder so that the

drivers on the tool holder grip the opening

in the discs.

m

Risk of injury from the rotating tools!

While the appliance is operating, never

place fingers in the mixing bowl. Always

use the pusher for adding ingredients.

After switching off, the drive continues

running for a short time. Change tools

only when the drive is at a standstill.

m

Risk of injury from sharp blades!

Do not touch blades of the universal blade

with bare hands. When not in use, always

store the universal blade in the blade

guard. Grip the universal blade by the

edge of the plastic handle only.

m

Risk of injury from sharp blades!

Do not grip the sharp blades or edges of

the cutting discs. Take hold of discs by the

edge only! Do not place fingers in the feed

tube. Only use the pusher when adding

more ingredients.

MCM3_alle.book Seite 16 Donnerstag, 12. Februar 2015 4:40 16

Robert Bosch Hausgeräte GmbH 17

en

 Attach lid with pusher (match arrow on lid

to arrow on bowl) and rotate in a clock-

wise direction. Lid lug must be located

fully in the slot in the bowl handle.

 Insert the mains plug.

 Set the rotary switch to the desired

setting.

 Fill with contents which are to be sliced

or shredded.

 When adding contents which are to

be sliced or shredded, apply only light

pressure to the pusher. Remove the

pusher and add ingredients through

the feed tube.

Warning!

Empty the bowl before it becomes so full

that the cutting or grating contents reach

the carrier disc.

After using the appliance

 Set the rotary switch to 0/off.

 Remove mains plug.

 Rotate the lid in an anti-clockwise

direction and remove.

 Remove tool:

– Take tool holder together with

universal blade, whisking disc or

kneading hook out of the bowl.

Remove the tools from the tool holder.

– Take out the cutting discs by the

plastic stud in the centre. Take tool

holder out of the bowl.

 Rotate bowl anti-clockwise and remove.

 Clean all parts, see “Cleaning and

servicing”.

Blender

Blade insert with blender/cutting blade for

mixing liquid or semi-solid food, for cutting/

chopping raw fruit and vegetables, for

puréeing food.

Warning!

Blender may be damaged. Do not process

deep-frozen ingredients (except ice cubes).

Do not operate blender when empty.

Fig. 

 Place seal on the blade insert. Ensure

that the seal is positioned correctly.

 Insert blade insert with blender/cutting

blade into the blender jug and lock

anti-clockwise ( ).

 Turn blender jug over (blade insert face

down).

 Attach the blender jug (match arrow on

the jug to the arrow on the appliance) and

rotate as far as possible in a clockwise

direction.

 Add ingredients.

Maximum capacity, liquid = 1.0 litres

(frothing or hot liquids max. 0.4 litres).

Optimal processing capacity – solids =

80 g.

 Attach lid and press firmly.

Hold lid while working.

 Insert the mains plug.

 Set the rotary switch to the desired

setting.

 To add more ingredients, set the rotary

switch to 0

/off.

 Remove the lid and add ingredients

or

 remove the funnel and gradually add solid

ingredients through the refill opening

or

 pour liquid ingredients through the funnel.

After using the appliance

 Set the rotary switch to 0/off.

 Remove mains plug.

 Rotate the blender in an anti-clockwise

direction and remove.

 Remove lid.

m

Risk of injury from sharp blades/

rotating drive!

Never place fingers in the attached

blender!

Do not remove/attach the blender until the

drive is at a standstill.

Do not touch blades of the blade insert

with bare hands. Clean them with a brush.

m

Risk of scalding!

If processing hot liquids, steam escapes

through the funnel in the lid. Add a max.

0,4 litres of hot or frothing liquid.

Important information

If the seal is damaged or not correctly

positioned, liquid may run out.

MCM3_alle.book Seite 17 Donnerstag, 12. Februar 2015 4:40 16


