Руководство Bosch BWD41740 AquaWash&Clean Пылесос

Руководство

14

18

Small nozzle

19

Crevice nozzle

20

Telescopic suction tube

21

Suction hose

22

Dust bag holder

23

Water lter module:

A

Filtration unit

B

Partition

24

Container

25

Cleaning liquid container

26

Spray unit – suction hose handle attachment

27

Large atomizing nozzle

28

Small atomizing nozzle

29

Water pick up nozzle (BWD41720, BWD420HYG,

BWD421PET, BWD421PRO)

30

Rubber slat to the large atomizing nozzle

31

Washing set

32

Foam lter I (installed in the vacuum cleaner)

33

Foam lter II (installed in the vacuum cleaner)

34

Motor lter (installed in the vacuum cleaner)

35

EPA/HEPA outlet lter (installed in the vacuum cleaner)

Preparing the vacuum cleaner for

operation

1

Insert the end of the suction hose to the vacuum cleaner

opening so that the markings on the hose end and on the

vacuum cleaner housing are opposite each other and turn

the hose clockwise to the position

.

2

Connect the other end of the hose (handle) with the

telescopic suction tube.

3

Hold the ring on the pipe and set chosen length putting it

in or out.

4

Assemble the appropriate nozzle or brush to the other

end of the suction tube.

5

Use the following nozzles and brushes for traditional using

the water lter module: combination carpet & oor brush with

small objects separator, small nozzle, small brush, crevice

nozzle, mattress nozzle, parquet brush or turbo brush.

6

You may assemble a basket for picking up small objects

in the combination brush with small item separator. In order

to do so remove the basket cover and insert the basket.

7

To clean hard surfaces – wooden oors, plastic oors,

ceramic tiles etc. pull out the brush by pressing the switch on

the nozzle according to the gure .

8

The vacuum cleaner is equipped with an accessory

compartment. The compartment opens/closes with the use

of a slider. To open/close the compartment side the slider

downwards/upwards and take out/ put away the desired nozzle.

9

The vacuum cleaner may be stored in a horizontal

B

position; in order to this, place the fastening hook of the

combination nozzle/brush into its fastening. The hose may

be left attached to the vacuum cleaner, but it is important to

pay attention not to leave it heavily bent during storage.

10

Close the lid.

11

Grab the plug (4) and pull the cord out of the vacuum

cleaner.

●

Plug in the appliance.

Before switching on the vacuum cleaner

with the on/off button (8), make sure that the

appropriate module is installed in the container

(see section C, E, or F).

12

Switch on the vacuum cleaner by pressing the “on/off”

button (8).

In order to prepare the vacuum cleaner for wet operation

additionally:

13

Assemble the spray unit – the suction hose handle

attachment (26).

●

Attach the hose fastenings to the suction hose and the

telescopic suction tube.

14

Attach the end of the hose (sleeve) to the telescopic

suction tube and insert the other end of the hose in the small

atomizing nozzle or the large atomizing nozzle until you hear

a characteristic click.

15

Use the following nozzles for the wet vacuuming and wet

cleaning function or to pick up water: large atomizing nozzle,

small atomizing nozzle or the water pick up nozzle.

16

Slide the stub pipe valve plug downwards.

●

Insert the stub pipe of the hose to the valve in the

vacuum cleaner housing.

●

Make sure the stub pipe fastenings snap shut.

In case of difculties in connecting the above

mentioned elements moisten the gaskets e.g.

with technical vaseline, water, etc.

Vacuum cleaner functions

TRADITIONAL CLEANING WITH DUST BAG

1

Press and hold the container lid opening button (2) and

lift the container lid.

2

Put the holder (22) into the container. Make sure the

holder is inserted correctly in the container guide slots and

the safety lock is engaged. Unfold the bag in the container.

Do not put holder into a wet container.

Thoroughly dry a wet container. Dust bag must

not get wet.

3

Cover the container with the ltration unit.

If the holder is not attached properly, the safety

lock will prevent covering the container with

the ltration unit.

C
