3. Secure the Mounting Bracket (L) to the wall.

4. Hang the main body on the Mounting Bracket.

Turning the unit on/off and setting the

Digital Thermostat (BPH1520 Only)

1. Plug unit into wall socket.

2. Locate on/off switch on the bottom of the

right end cap and switch to the on position.

3. Press ( ) Mode button (F):

• 1

st

= LO; runs continuously on Low.

• 2

nd

= HI; runs continuously on High.

• 3

rd

= Auto Low (AL); press (+) or (-)

to set desired temperature.

• 4

th

= Auto HI (AH); press (+) or (-)

to set desired temperature.

4. Once you have selected the mode and

temperature, the display returns to the

current room temperature and gradually

increases as the room warms.

5. If you selected an Auto mode and the

heater does not start, make sure the set

temperature is higher than the current

room temperature.

6. To turn the unit off keep pressing the mode

button (F) until all mode indicator lights (E)

are not illuminated.

7. Switch off the on/off switch located on the

bottom of the right end cap.

NOTE: The mode Indicator Light (E)

will flash in the AUTO mode if the set

temperature is lower than the current

room temperate displayed on the

Display, this is also the same if the

unit has reached the required set

temperature.

NOTE: In Auto mode, it is normal for

the heater to cycle ON and OFF as it

maintains the programmed temperature.

To prevent the unit from cycling, raise

the thermostat setting.

The Digital Thermostat remembers the

previous temperature setting after the

unit is turned off. However, if the unit

is unplugged, the digital thermostat

resets and no longer remembers the

previous temperature setting.

Turning the unit on/off and setting the

thermostat (BPH1414 Only)

1. Plug unit into wall socket.

2. Rotate the mode adjustment knob clockwise

from the (0) position to either 1 (Low setting) or

2 (High setting) to get a constant heat output.

3. To find the ideal thermostat setting, turn

the thermostat adjustment knob clockwise

to “max”.

4. When the desired temperature is reached

slowly turn the thermostat knob anti-clockwise

until the heater turns off.

5. The heater will now automatically retain

the temperature at the required level.

6. To turn the unit off rotate the mode

adjustment knob anti-clockwise to the

(0) position.

PROGRAMMABLE TIMER (BPH1520 Only)

You can program your heater to turn on at a

preset time or turn off after a set amount of time.

Setting the On Timer:

1. With the heater off, press and hold (+) and

(-) simultaneously until the display flashes

and display the number “0”.

2. Press (+) or (-) to select the amount of time you

would like to pass before the heater turns on.

3. After setting the timer, the display shows

a red dot next to the current room

temperature on the display to indicate

that the timer is activated.

4. After the programmed length of time has

passed, the heater automatically turns on

Auto HI at 24°C (75°F) for 2 hours.

Setting the Off Timer:

1. Select the desired mode and/or temperature.

2. With the heater running, press and hold (+)

and (-) simultaneously until the display flashes.

3. Press (+) or (-) to select the amount of time

you would like the heater to run.

4. After setting the timer, the display shows a

RED dot next to current room temperature on

the display to indicate that the timer is activated.

5. The heater automatically shuts off after the

programmed length of time has passed.

FROST GUARD (BPH1520)

Press the( ) Mode button 5 consecutive times

for Anti Frost setting (AF will show in the digital

display). This special setting is automatically

activated when the (AF) mode is selected. In this

mode, the heater is off until the room’s temperature

reaches freezing and the heater automatically turns

on HI power. The heater will cycle ON and OFF

as it maintains the temperature between 5-8 °C.

FROST GUARD (BPH1414)

Keep unit in 1 (low setting) or 2 (high setting)

rotate thermostat adjustment knob to beginning

position ( ). Unit will stop working. This special

setting is automatically activated. In this mode, the

heater is off until the room’s temperature reaches

freezing and the heater automatically turns on HI

power. The heater will cycle ON and OFF as it

maintains the temperature between 5-8 °C.

AUTO SAFETY SHUT OFF

The heater has a built in safety device which

will switch off the heater automatically in case

of accidental overheating. It can only resume

operation when the user has reset the unit. For the

BPH1520 (OH) will display in an overheat situation.

RETAIN THE FOLLOWING FOR

FUTURE REFERENCE.

DESCRIPTIONS (See Fig.1 & 2)

A. Left End Cap

B. Rear Housing

C. Right End Cap

D. Display

E. Mode Indicator Lights

F. Mode Button/Adjustment

G. Thermostat Adjustment

H. Base

I. Grill

J. Power light

K. Base Mount

L. Mounting Bracket (Figure 5)

PLEASE READ AND SAVE THESE

IMPORTANT INSTRUCTIONS

When using electrical appliances, basic safety

precautions should always be taken including

the following:

1. Before connecting the heater, check that the

voltage indicated on the rating plate

corresponds to the main voltage in your

home/office.

2. WARNING: In order to avoid overheating,

do not cover the heater ( ).

3. DO NOT position the heater directly under a

power socket.

4. Do not use this heater in the immediate

surroundings of a bath, a shower or a

swimming pool.

5. If the supply cord or plug is damaged, it must

be replaced by the manufacturer or its service

agent or similarly qualified person in order to

avoid hazard. The heater contains no user

serviceable parts. Should the product suffer

damage or breakdown, it must be returned to

the manufacturer or their service agent.

6. Under the environment with electrical fast

transient, the product may malfunction and

require user to reset the product.

7. Do not use this heater with a programmer,

timer or any other device that switches

the heater on automatically, since a fire

risk exists if the heater is covered or

positioned incorrectly.

8. Only touch the heater with dry hands.

9. DO NOT use this heater outdoors.

10. DO NOT position where it can be touched by

children, especially the very young.

11. Allow a safe area around the heater away

from furniture or other objects; at least

50 cm from the top and sides and 200 cm

at the front.

12. Do not use this heater when it is lying on

its side.

13. DO NOT use the heater in rooms with

explosive gas (e.g. petrol) or while using

inflammable glue or solvent (e.g. when

gluing or varnishing parquet floors, PVC etc.)

14. DO NOT insert any objects into the heater.

15. Keep the mains cord at a safe distance from

the main body of the heater.

16. If overheating should occur, the built-in

overheating safety device will switch off

the heater.

17. Do not place the cord under a rug.

18. The heater is to be installed so that switches

and other controls cannot be touched by a

person in the bath.

19. Heater must be installed at least 0.6 m

above the floor.

20. The heater cannot be used adjacent to

curtains or combustible material. Curtains or

combustible material may be burned if the

heater was installed incorrectly.

21. This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities, or

lack of experience and knowledge, unless

they have been given supervision or

instruction concerning use of the appliance

by a person responsible for their safety.

Children should be supervised to ensure that

they do not play with the appliance.

22. WARNING: Risk of Fire. Discontinue use if the

outlet or plug become hot to the touch.

Overheating may indicate a worn or damaged

outlet. Consult a qualified electrician for

outlet replacement.

23. CAUTION: In order to avoid a hazard due

to inadvertent resetting of the thermal cut-

out, this appliance must not be supplied

through an external switching device, such

as a timer, or connected to a circuit that is

regularly switched on and off by the utility.

BASE ASSEMBLY (See Fig. 3)

1. Insert base (H) into the bottom of the base

mount (K) which is attached to the bottom of

the Grill (I).

WALL MOUNTING ASSEMBLY

(See Fig. 4 – Fig. 6)

IMPORTANT: Before drilling into any wall

ensure no electrical cables are present in the

area.

NOTE: Due to the multitude of potential

mounting surfaces, mounting screws are not

included with this product. Please seek

professional assistance or visit your local

hardware store to determine which type of screw

is best for your particular wall.

1. Remove Base (H) from the bottom of the

Base Mount (K).

2. Remove Base Mount from the bottom of the

Grill (I) by removing the two securing screws.

ENGLISH

2

BPH1414-1520-I_IM-REV2.qxd:BPH1515I06MLM1.qxd 4/30/09 11:03 AM Page 2
